This historic book may have numerous typos and missing text. Purchasers can download a free scanned copy of the original book (without typos) from the publisher. Not indexed. Not illustrated. 1895 Excerpt:... Cross stays for bogie pin. 118. Axles for bogie wheels. Driving wheel and axle, Figs. 377 to 379:--119. Driving wheel. 120. Driving axle. 121. Crank, cast to gether with boss of driving wheel. 122. Crank pin. 123. Bearingsofdrivingaxle. 124. Guide blocks of bear ings. 125. Adjusting block, or wedge of bearings. 126. Bearing spring of driv ing axle. 127. Shoe of bearing spring. 128. Spring harness. 129. Adjusting screw for wedge, 125. 130. Horn plates. 131. Driving-wheel cover. 132. Crank-pin cover. Trailing wheels, Figs. 380 to 382:--133. Trailing wheels. 134. Trailing axles. 135. Bearing for trailing axle. 136. Guide plates for bearings. 137. Spiral springs for trailing end of engine. 138. Frame for carrying spiral springs. 139. Horn plates for trailing axle. The engine has in addition:--140. Cover for protecting stand of driver. 141. Awnings or eye-glasses for drivers. Fig. 375. Fig. 383. Fig. 383 shows a locomotive boiler in section, with some of the detail of steam supply and exhaust tubes, safety valves, tc. This, however, differs from Fig. 358 in having a domed steam chamber on the top of the boiler, about the middle, from whence the supply-pipe to the cylinders is taken, and to which the safety-valve is fixed. An auxiliary safety-valve is shown over the fire-box similar to Fig. 369. The majority of engineers favour the use of this domed chamber, as will be seen from the following: examples, but it is not of absolute necessity for the engine's actual efficiency. No locomotive boilers are arranged to quite fill with water, although it is very necessary that the level be kept above the internal tubes. This admits of a sufficient steam generating chamber, but as from ebullition and other causes the water is agitated violently, the dome allows of the ent...
Page Count:
126
Publication Date:
2012-01-01
ISBN-10:
1231208643
ISBN-13:
9781231208649
