This historic book may have numerous typos and missing text. Purchasers can usually download a free scanned copy of the original book (without typos) from the publisher. Not indexed. Not illustrated. 1905 edition. Excerpt:... Tile Elevators on No. 57 link-belt, with 30x21 Trays, 16-inch drop, arranged to drive at foot, complete except driving gear and frame work. Driving Gear for above, as shown in cut, $26.50. Extra Tays, $4.00 each. MACHINERY COMPANY CHICAGO The "Link-Belt" Box Water Elevator is the simplest and most economical means of lifting water yet designed. It has been in successful operation for the past 15 years in the irrigation districts of the West, and large numbers are used for flooding ponds, draining marshes, clay pits, etc. There are no dead-centers or return strokes, conse-quently a steady flow is always assured. Simple in construction and easily repaired. Prices on larger elevators furnished on application stating capacity in gallons per minute, and lift. In ordering Driving Machinery please give: 1. Diameter of driving shaft; 2. Number of turns per minute made by driving shaft; 3. Distance of driving shaft from elevator head shaft; and 4. State whether driving shaft and head shaft will revolve in the same or opposite directions. We do not manufacture or deal in wind mills, water wheels, or engines of any kind. For prices on these apply to a local dealer, or the manufacturer. Price List MACHINERY OUTFIT. fIncluding head and foot shafts, with gap wheels, lournal boxes, take-ups and collars, and necessary elevator belting with flights.) Without wood-work or driving connections. MACHINERY COMPANY CHICAGO Conveyors The Single Strand Flight Conveyor Extensively employed for handling sawdust, grain or other bulk material not of a gritty nature. Its most common form of construchown above. To relieve the n sliding friction the flights are and the chain inserted to a suf: pth to raise it clear of the trough bottom. This result can be...
