Author Description

This historic book may have numerous typos and missing text. Purchasers can download a free scanned copy of the original book (without typos) from the publisher. Not indexed. Not illustrated. 1904 Excerpt:...useless. A general drawing should clearly hint at, but not specify, detailed design. It is just as valuable a part of the design as the detail drawing, but it cannot be made to answer for both with any degree of success. A good general drawing has plenty of views, and an abundance of cross sections, but few dotted lines. The general drawing of the machine under consideration ia left for the student to work up from the complete details shown. It would look something like the preliminary layout of Fig. 10, if the same were carefully carried out to finished form. A plain outside view would probably be more satisfactory in this case than a cross section, as the latter would show little more of value than the former. The functions which the general drawing may serve are many and varied. Its principal usefulness is, perhaps, in showing to the workman how the various parts go together, enabling him to sort out readily the finished detail parts and assemble them, finally producing the complete structure. Otherwise the making of a machine, even with the parts all at hand, would be like the putting together of the many parts of an intricate puzzle, and much time i would be wasted in trying to make the several parts fit, with perhaps never complete success in giving each its absolutely correct location. The general drawing also gives valuable information as to the total space occupied by the completed machine, enabling its location in a crowded manufacturing plant to be planned for, its connection to the main driving element arranged, and its convenience of operation studied. In some classes of work it is a convenient practice to letter each part on the general drawing, and to note the same letters on the specification or order sheet, thus enabling the whole machine t...
